Specifications
| Weight | 0.1 kg |
|---|---|
| Manufacturer | Wenglor |
| Model | WENGLOR IB040BM46VD3 Reflex Sensor with Background Suppression |
| Condition |
WENGLOR IB040BM46VD3 Reflex Sensor with Background Suppression
We are NOT an authorized distributor for Wenglor
- ManufacturerWenglor
- ModelWENGLOR IB040BM46VD3 Reflex Sensor with Background Suppression
- SKU051021
27 $
1 in stock
Description
Manufacturer: WENGLOR
Model: IB040BM46VD8
Type: Inductive Sensor with Standard Switching Distances
Switching Distance: 4 mm
Correction Factors Stainless Steel V2A/CuZn/Al: 0,77/0,50/0,48
Mounting: Flush
PNP NC: yes
Supply Voltage: 10 … 30 V DC
Current Consumption (Ub = 24 V): < 6 mA
Switching Frequency: 700 Hz
Temperature Drift: < 10 %
Temperature Range: -25 … 80 °C
Switching Output Voltage Drop: < 2.5 V
Switching Output/Switching Current: 200 mA
Protection Class: III
Degree of Protection: IP67
Connection: M8 × 1; 3-pin
