Specifications
| Weight | 0.300 kg |
|---|---|
| Manufacturer | IFM |
| Model | |
| Part Number | IB-2020-BBOA |
| Sensor Type | Inductive sensor |
| Sensing Range | 20 mm |
| Switching Type | NC |
| Output Type | AC/DC |
| Condition |
IFM IB0017 Inductive sensor IB-2020-BBOA
We are NOT an authorized distributor for IFM
- ManufacturerIFM
- ModelIB0017
- SKU050655
32 $
4 in stock
Description
Manufacturer: IFM
Type: Inductive sensor
Model: IB0017
Part No.: IB-2020-BBOA
Output function: normally closed
Sensing range [mm]: 20
Housing: cylindrical
Dimensions [mm]: Ø 34 / L = 82
Operating voltage [V]: 20…250 AC/DC
Protection class: II
Reverse polarity protection: no
Max. voltage drop switching output DC [V]: 6
Max. voltage drop switching output AC [V]: 6.5
Minimum load current [mA]: 5
Max. leakage current [mA]: 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC)
Permanent current rating of switching output AC [mA]: 250; (350 up to +50 °C)
Permanent current rating of switching output DC [mA]: 100
Short-time current rating of switching output [mA]: 2200; (20 ms / 0.5 Hz)
Switching frequency AC [Hz]: 25
Switching frequency DC [Hz]: 50
Short-circuit protection: no
Overload protection: no
