Specifications
| Weight | 0.200 kg |
|---|---|
| Manufacturer | IFM |
| Model | |
| Part Number | IA-3010-APKG |
| Sensor Type | Inductive sensor |
| Sensing Range | 10 mm |
| Switching Type | NC |
| Output Type | PNP |
| Condition |
IFM IA5050 Inductive sensor IA-3010-APKG
We are NOT an authorized distributor for IFM
- ManufacturerIFM
- ModelIA5050
- SKU050643
57 $
3 in stock
Description
Manufacturer: IFM
Type: Inductive sensor
Model: IA5050
Part No.: IA-3010-APKG
Electrical design: PNP
Output function: normally closed
Sensing range [mm]: 10
Housing: cylindrical
Dimensions [mm]: Ø 20 / L = 77
Operating voltage [V]: 10…36 DC
Current consumption [mA]: 15; (24 V)
Protection class: II
Reverse polarity protection: yes
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 250
Switching frequency DC [Hz]: 300
Short-circuit protection: yes
Type of short-circuit protection: pulsed
Overload protection: yes
Ambient temperature [°C]: -25…80
Protection: IP 67
