Specifications
| Weight | 0.250 kg |
|---|---|
| Manufacturer | IFM |
| Model | |
| Part Number | SID10ADB10OG/ |
| Condition |
IFM SI5004 Flow transmitter SID10ADB10OG/
We are NOT an authorized distributor for IFM
- ManufacturerIFM
- ModelSI5004
- SKU052929
210 $
3 in stock
Description
Manufacturer: IFM
Model: SI5004
Type: Flow Transmitter
Part Number: SID10ADB10OG/
Technical Specifications:
-
Pressure rating: 300 bar
-
MAWP (CRN applications): 208 bar
-
Operating voltage: 19…36 V DC
-
Current consumption: < 60 mA
-
Analogue current output: 4…20 mA
-
Probe length: 45 mm
-
Setting range: 3…300 cm/s
-
Greatest sensitivity: 3…100 cm/s
-
Repeatability: 1…5 cm/s
-
Response time: 1…10 s
-
Ambient temperature: -25…80°C
-
Protection: IP67
-
Dimensions: M18 x 1.5 mm
-
Thread designation: M18 x 1.5
-
Connection: 1 x M12 Connector, Coding A
