Specifications
| Weight | 0.150 kg |
|---|---|
| Manufacturer | Panasonic |
| Model | |
| Part Number | DP-100 |
| Condition |
Panasonic DP-101-E-P PRESSURE SENSOR DP-100 (10 TO 24V)
We are NOT an authorized distributor for Panasonic
- ManufacturerPanasonic
- ModelDP-101-E-P
- SKU052554
38 $
1 in stock
Description
Manufacturer: Panasonic
Type: Pressure Sensor
Model: DP-101-E-P
Supply Voltage: 12 to 24 V DC ±10% (Ripple P-P 10% or less)
Rated Pressure Range: -100.0 to +100.0 kPa
Set Pressure Range:
-
-101.0 to +101.0 kPa
-
-1.030 to +1.030 kgf/cm²
-
-1.010 to +1.010 bar
-
-14.64 to +14.64 psi
-
-757 to +757 mmHg
-
-29.8 to +29.8 inHg
Contact Type: PNP Open-Collector Transistor
Comparative Output: NO / NC Selectable
Pressure Port: M5 Female Thread + G 1/8 Male Thread
Protection Class: IP40
Operating Temperature: -10 to 50 °C
